The Company has 4 sets 650 HP drilling rigs. It is a self-propelled drilling rig, mainly composed of a self-propelled chassis, on-board operating mechanism, and drilling accessories. It is easy to transfer and install on the well site and can meet the needs of high-load and long-term continuous drilling operations. The drilling rig has an in-operation height of 35 m, a maximum static hook load of 1,580 kN, a nominal drilling depth of 2,000 m (4-1/2" drill pipe), and the winch power is 650 HP.

Parameters of drilling rig

Nominal drilling depth: 4 1/2′′ drill pipe 2,000 m Winch power: 650 HP

Maximum static load: 1,580 kN (4 × 5)

Engine power: 470 kW/2,100 rpm (630 HP/2,100 rpm) Height of derrick: 35 m (Y-shaped rear derrick) Traveling system: effective drilling lines, 8

Wire rope diameter: 29 mm (6 × 19)

Lifting speed of hook: 0.2~1.5 m/s

Turntable diameter: 444.5 mm (17 1/2")

Faucet center pipe diameter: 76 mm

Base surface height: 4.5/5 m

Transmission mode: hydraulic + mechanical

Moving overall dimensions (length × width × height): 20.5 m × 3.05 m × 4.3 m

The Company has 3 x 750 HP drilling rigs. It is a self-propelled drilling rig, mainly composed of a self-propelled chassis, on-board operating mechanism, and drilling accessories. It is easy to transfer and install on the well site and can meet the needs of high-load and long-term continuous drilling operations. The drilling rig has an in-operation height of 38 m, a maximum static hook load of 1,800 kN, a nominal drilling depth of 3,000 m (4-1/2" drill pipe), and the winch power is 750 HP.

Parameters of drilling rig

Nominal drilling depth: 4 1/2′′ drill pipe 3,000 m

Winch power: 750 HP

Maximum static load: 1,800 kN (5 × 6)

Engine power: 403 kW (540 HP)/2,100 r/min (double engines) Height of derrick: 38 m (Y-shaped rear derrick)

Traveling system: effective drilling lines, 10 Wire rope diameter: 32 mm (6 × 19) Lifting speed of hook: 0.2~1.5 m/s Turntable diameter: 698.5 mm (27 1/2") Faucet center pipe diameter: 76 mm

Turntable diameter: 444.5 mm (17 1/2")

Base surface height: 6 m

Transmission mode: hydraulic + mechanical

Transmission mode: hydraulic + mechanical

Moving overall dimensions (length × width × height): 22 m × 3.5 m × 4.6 m

The Company has 4 sets of 1,000 HP drilling rigs. It is a self-propelled drilling rig, mainly composed of a self-propelled chassis, on- board operating mechanism, and drilling accessories. It is easy to transfer and install on the well site and can meet the needs of high- load and long-term continuous drilling operations. The drilling rig has an in-operation height of 38 m, a maximum static hook load of 2,250 kN, a nominal drilling depth of 4,000 m (4-1/2" drill pipe), and the winch power is 1,000 HP.

Parameters of drilling rig

Nominal drilling depth: 4 1/2′′ drill pipe 4,000 m

Winch power: 1,000 HP

Maximum static load: 2,250 kN (6 × 5)

Engine power: 470 kW (630 HP)/2,100 r/min (double engines) Height of derrick: 38 m (Y-shaped rear derrick)

Traveling system: effective drilling lines, 10 Wire rope diameter: 32 mm (6 × 19) Lifting speed of hook: 0.2~1.5 m/s Turntable diameter: 698.5 mm (27 1/2") Faucet center pipe diameter: 76 mm

Base surface height: 6 m

Transmission mode: hydraulic + mechanical

Moving overall dimensions (length × width × height): 23 m × 3.5 m × 4.6 m

The Company has 2 sets of 1,500 HP drilling rigs, which adopt mechanical-electric drives. Three G12V190PZL-1 diesel engines are provided at the rear block of the drilling rig to drive the integral chain transmission box via the hydraulic coupling. After paralleling, the power drives two F1600 mud pumps respectively and also drives the winch through the integral chain box. The derrick is K-shaped, with low rooting, which can meet the requirements of top drive installation; the rig base is of a high-front and low-rear structure. The drill block is 9 m high, and the rear bock is 0.56 m high. The winch power is 1,500 HP, and the winch is installed on a 1.2 m high winch base at a low position.

Parameters of drilling rig

Nominal drilling depth (114 mm drill pipe): 5,000 m Maximum hook load: 3,150 kN

Rated power of winch: 1,500 HP

Main brake: Hydraulic disc brake

Auxiliary brake: Air-cooled electromagnetic brake Diameter of wire rope: 35 mm

Ropes of lifting system: 6 × 7 sequent pulling

Opening diameter of turntable: 698.5 mm

Gears of turntable: Two gears, stepless speed regulation

Model and quantity of mud pump: 1,600 HP × 2 Maximum working pressure of mud pump: 35 MPa Type and height of derrick: K type, 45 m

Height of drill block surface: 9 m Clearance height of base: 7.4 m Model of diesel engine: G12V190PZL-3/O

The Company has another model of 1,500 HP drilling rig. This drilling rig adopts electromechanical and digital integration design, which enables the digital control of main functions in an automatic, intelligent and information-based way. The winch, turntable and mud pump are all driven by independent AC variable frequency drive systems without mutual interference. By such an arrangement, the requirements of drilling process can be better satisfied. The electric transmission is through a vector variable frequency drive system, and the main electrical equipment is arranged in the VFD room. The winch power is 1,500 HP. The rig is equipped with an integrated driller control room, in which the main operations of the drilling rig are performed by the driller and the real-time display and storage of parameters (signals) are realized.

Parameters of drilling rig

Nominal drilling depth (114 mm drill pipe) 7,000 m

Maximum hook load Rated power of winch

Gears of winch

Main brake

Auxiliary brake

Diameter of wire rope: 38 mm

Ropes of lifting system

Maximum fast line tension

Opening diameter of turntable

Gears of turntable Two gears, stepless speed regulation Model and quantity of mud pump 1,600 hp × 2

Maximum input power of single mud pump 1,193 kW (1,600 hp) Maximum working pressure of mud pump 35 MPa

Type and height of derrick Height of drill block surface Clearance height of base Model/quantity of diesel engine

Clearance height of base: 7.m

Power transmission mode: AC-DC-AC, full digital frequency conversion

K type, 45.5 m 10.5 m 9 m

G12V190PZL-3/O×4
